| Model | MK330 (12'') | MK630(24'') | MK1200(48'') | MK1500(60'') |
| Media Way | Desk cutter | Floor Stand | Floor Stand | Floor Stand |
| Main Board | High-performance & intelligent ARM 32 CPU; 128MB memory | |||
| Driver | High speed stepping motor, micro-step driver | |||
| Max Paper Feed Width | 430mm | 730mm | 1300mm | 1600mm |
| Max Cutting Width | 330mm | 630mm | 1200mm | 1500mm |
| Max Cutting Speed | 650mm/s | |||
| Cutting Force | 0-500g/0-1000g (optional configuration) | |||
| Mechanical Precision | 0.05mm | |||
| Repeatable Precision | < +-0.1mm | |||
| Plotter Instruction | DM-PL/HP-GLAutomatic Identification | |||
| Interfaces | USB / Serial port | |||
| Power Supply | AC110V /220V±10%, 50Hz/60Hz | |||
| Software | Plug-in for Coreldraw, Artcut, Signcut and Signmaster | |||
| Noise at Work | ≤50 DB | |||
| External Dimension | 750*330*400mm | 1045*330*400mm | 1590*330*400mm | 1890*330*400mm |
| Shipping Weight | 15kgs | 22kgs | 32kgs | 45kgs |
| Features | Picture |
| 1:With laser sensor(contour function) | |
| 2: High force to cut reflective film | |
| 3: Real high speed 128MB memory | |
4:High precision steel roller: guaranteed 3m without diviation of paper feeding | |
| 5:Low noise:ultra quiet design | |
| 6:High performance 32-bit processor with ARM Cortex-M3 | |
7:high accuracy machine structure allows to cut 2mm letters without distortation | |
| 8.Support CoreIDRAW output directly | |
| Accessary: | |
| 1 x power cord 1 x Manual | |
| 1 x Blade holder 3 x Blade | |
| 1 x Pen holder | |
| 1 x RS232 data cable | |
| 1 x USB data cable |
Feature of vinyl cutter
1 Big LCD easy touch silicone button,working for 5 years without demage.
2 Optional 1000g high force to cut strong 3M reflective film.Normal force to cut different materials. Such as sticker, car sticker, war sticker, reflective film and some others.
3 Max cutting speed 650 mm/s.
4 High precision steel roller: guaranteed 5 meters without deviation of paper feeding. All machine adopt this way, to make all our machines with high precision.
5 Support cut 2mm small letters without distortion
6 High performance 32-bit processor with ARM Cortex-M3
Advantages:
1: We are the first to supply designs of integrated carriage head in China,our plotter has strong torque rigid structure, to ensure the verticality of three axis, making higher precision during cutting.
2: We use imported high-precision integrated steel roller which has stronger grasping force,to ensure the cutting plotter works cutting in 5-8 meters without material deviation .
3: We use the advanced double power motor, microstep driving mode, to supply enough power for the cutting plotter.
4: We use all aluminum material plus metal design for the plotter outcase, it is firm and fashionable and higher quality.
5:We use large screen and LED silicone keypads to display clear,and easy to operate for customers. Chinese and English language display helps you to operate simply.
6: We use the advanced ARM-32 bit Core MCU designed motherboard,which perfectly work with the software and the machine.
7: We use Super ram, even customers cut large files without any problem.
8: We use shielding box anti-interference power supply, to ensure the machine working more stable and reliable.
9:We supply USB and serial dual interface, compatible operating system any version of Windows .
10: The plotter is compatible withArtcut ,signmaster,coreldraw,Flexi software,it helps customers have more choice to cut!
